200,00800,00 HT


NAS 4 baies LFF

CPU – Intel Atom à 2,1 GHz
Mémoire – 1Go RAM SO-DIMM (extensible jusqu’à 3Go)
Mémoire flash : 512Mo
Types de disques compatibles – 4 disques SSD/HDD SATA 3,5″ ou 2,5″ (disques durs non inclus)
Disque dur remplaçable à chaud – Oui
Port externe  : 2 ports USB 3.2 + USB2.0 / 1x HDMI + 1x VGA / 2 ports eSATA
LAN – 2x RJ-45 de 1GbE
Ventilateur système – 1 quiet

UGS : TS-469LCatégories : , , Étiquettes : , , , ,



NAS 4 baies LFF

CPU – Intel Atom à 2,1 GHz
Mémoire – 1Go RAM SO-DIMM (extensible jusqu’à 3Go)
Mémoire flash : 512Mo
Types de disques compatibles – 4 disques SSD/HDD SATA 3,5″ ou 2,5″ (disques durs non inclus)
Disque dur remplaçable à chaud – Oui
Port externe  : 2 ports USB 3.2 + USB2.0 / 1x HDMI + 1x VGA / 2 ports eSATA
LAN – 2x RJ-45 de 1GbE
Ventilateur système – 1 quiet

Operating System
QNAP Turbo System (QTS) 3.7, embedded Linux
  1. iSCSI Target
    • Multi-LUNs per Target
    • Up to 256 Targets/LUNs Combined
    • Supports LUN Mapping & Masking
    • Online LUN Capacity Expansion
    • Supports SPC-3 Persistent Reservation
    • Supports MPIO & MC/S
  2. iSCSI LUN Backup, One-time Snapshot, and Restore
  3. iSCSI Connection and Management by QNAP Finder (Windows)
  4. Virtual Disk Drive (via iSCSI Initiator)
    • Stack Chaining Master
    • Max No. of Virtual Disk Drives: 8
Supported Clients
  1. Apple Mac OS 10.7 or later
  2. Linux and UNIX
  3. Microsoft Windows 7, 8, and 10
  4. Microsoft Windows Server 2003, 2008 R2, 2012, 2012 R2 and 2016
Server Virtualization & Clustering
  1. Supports VMware vSphere
  2. Supports Citrix XenServer
  3. Supports Windows Server 2008 R2 Hyper-V & Failover Clustering
Supported Browsers
  1. Microsoft Internet Explorer 10+
  2. Mozilla Firefox 8+
  3. Apple Safari 4+
  4. Google Chrome
Power Management
  1. Wake on LAN
  2. Internal Hard Drive Standby Mode
  3. Scheduled Power on/off (Max 15 Settings)
  4. Automatic Power on after Power Recovery
  5. USB and Network UPS Support with SNMP Management
Multilingual Support
  1. Chinese (Traditional & Simplified), Czech, Danish, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese (Brazil), Romanian, Russian, Spanish, Swedish, Thai, Turkish
Access Right Management
  1. Max No. of Users: 4,096
  2. Max No. of User Groups: 512
  3. Max No. of Network Shares: 512
  4. Batch Users Creation
  5. Import/Export Users
  6. User Quota Management
  7. Subfolder Permissions Support for CIFS/SMB, AFP, FTP and Web File Manager
File System
  1. Internal Hard Drive: EXT3, EXT4
  2. External Hard Drive: EXT3, EXT4, NTFS, FAT32, HFS+
Domain Authentication Integration
  1. Microsoft Active Directory (AD)
  2. LDAP Server
  3. LDAP Client
  4. Domain Users Login via CIFS/SMB, AFP, FTP, and Web File Manager
  1. TCP/IP (IPv4 & IPv6: Dual Stack)
  2. Dual Gigabit NICs with Jumbo Frame
    • Failover
    • Multi-IP Settings
    • Port Trunking/NIC Teaming (Modes: Balance-rr, Active Backup, Balance XOR, Broadcast, IEEE 802.3ad/Link Aggregation, Balance-tlb and Balance-alb)
  3. Service Binding based on Network Interfaces
  4. Virtual LAN (VLAN)
  5. DHCP Client, DHCP Server
  6. Protocols: CIFS/SMB, AFP (v3.3), NFS(v3), FTP, FTPS, SFTP, TFTP, HTTP(S), Telnet, SSH, iSCSI, SNMP, SMTP, and SMSC
  7. UPnP & Bonjour Discovery
  8. USB Wi-Fi Adapter Support
MyCloudNAS Service
  1. Private Cloud Storage and Sharing
  2. Free Host Name Registration (DDNS)
  3. Auto Router Configuration (via UPnP)
  4. MyCloudNAS Connect for Easy VPN Connection (Windows utility)
Backup Solution
  1. Real-time Remote Replication (RTRR)
    • Works as Both RTRR Server & Client with Bandwith Control
    • Real-time & Scheduled Backup
    • Encryption, Compression, File Filter, and Transfer Rate Limitation
  2. Block-level Remote Replication
    • Works as Both Rsync Server & Client with Bandwidth Control
    • Encrypted Replication between QNAP NAS Servers
  3. USB One Touch Backup (Import/Export)
  4. Desktop Backup by QNAP NetBak Replicator for Windows
  5. Apple Time Machine Support with Backup Management
  6. Data Backup to Multiple External Storage Devices
  7. Data Backup to Cloud Storage (Amazon S3, ElephantDrive)
Storage Plug & Play
  1. Windows Software: QNAP Finder
  2. Create and Map Shared Folders
  3. Create and Connect to iSCSI Target/LUN
  1. IP Filter and Policy-based Automatic IP Blocking
  2. Network Access Protection with Auto-blocking: SSH, Telnet, HTTP(S), FTP, CIFS/SMB, AFP
  3. Encrypted Access: HTTPS, FTP with SSL/TLS (Explicit), SSH/SFTP (admin only), Encrypted Remote Replication between QNAP NAS Servers (Rsync over SSH)
  4. CIFS Host Access Control for Shared Folders
  5. Antivirus Protection
  6. FIPS 140-2 Validated AES 256-bit Volume-based Data Encryption*
  7. AES 256-bit External Drive Encryption*
  8. Importable SSL Certificate
  9. Instant Alert via E-mail, SMS, and Beep
Web Administration
  • AJAX-based User Interface
  • Smart Fan Control
  • Dynamic DNS (DDNS)
  • SNMP (v2 & v3)
  • Resource Monitor
  • Network Recycle Bin for File Deletion via CIFS/SMB and AFP
    • Automatic Cleanup
    • File Type Filter
  • Comprehensive Logs (Events & Connection)
  • Syslog Client
  • Firmware Live Update
  • System Settings Backup and Restore
  • Restore to Factory Default
  • Mobile App Qmanager for Remote Monitoring
Disk Management
  1. Single Disk, JBOD, RAID 0, 1, 5, 6, 10, 5+hot spare
  2. Online RAID Capacity Expansion & Online RAID Level Migration
  3. Bad Block Scan & Hard Drive S.M.A.R.T.
  4. RAID Recovery
  5. Bitmap Support
Powerful All-in-one server
File Server
  1. File Sharing across Windows, Mac, and Linux/UNIX
  2. Windows ACL
  3. Advanced Folder Permission for SMB, AFP, FTP, Web File Manager
  4. Shared Folder Aggregation (CIFS/SMB)
  5. Web File Manager
    • Supports ISO Mounting
    • Direct File Viewing via Google Doc
    • Create and Send Download Links for Public File Sharing with Expiration Time and Password Protection
  6. Mobile App: Qfile for File Browsing and Management
  1. Protection against the Latest Known Viruses, Trojans, and Other Threats
  2. Free Virus Databases Update on Manual or Scheduled Basis
  3. Multiple Scan Tasks (Max: 64, Concurrent: 5) with Custom Folder Selection and Scheduled
  4. Scanning
  5. Email Notification upon Task Completion or Virus Detection
  6. Quarantines or Deletes Infected Files
FTP Server
  1. FTP over SSL/TLS (Explicit)
  2. Max No. of Concurrent Connections: 256
  3. FXP Supported
  4. Passive FTP Port Range Control
  5. FTP Bandwidth & Connection Control
  6. Unicode Support
Backup Server
  1. Remote Replication Server (over Rsync)
  2. Real-time Remote Replication to another QNAP NAS or FTP Server
  3. Apple Time Machine Support
  4. Windows Client Backup Application: QNAP NetBak Replicator
  5. Third Party Backup Software Support: Acronis True Image, CA BrightStor, ARCserve Backup, EMC Retrospect, Symantec Backup Exec, LaCie SilverKeeper, etc.
DLNA Server
  1. Supports DLNA/UPnP TVs and Players such as PlayStation 3 and Xbox 360
  2. Supported audio format: MP3, FLAC, OGG, WAV, AIF, AIFF, and more.
    *DRM encryption format is not supported.
  3. Support CUE indexing file for APE, FLAC audio format.
  4. Video and Audio On-the-fly Transcoding
Web Server
  1. HTTP/HTTPS Connections
  2. Supports WebDAV Connection
  3. Support Virtual Host (Max: 32)
  4. Importable SSL Certificate
Database Server
  1. Built-in MySQL Server
  2. Web-based Management via phpMyAdmin (QPKG)
Photo Station
  1. Supported File Formats:
    • Photo: BMP, JPG, JPE, PNG, TGA, GIF, and more.
    • Video: API, MP4, and more.
  2. Image Slideshow with Background Music, Thumbnails, and Different Playback Modes
  3. Online Photo Editing by Pixlr Editor
  4. Geotagging Photos with Google Maps
  5. Slideshow Sharing (from Private Albums) with Password Protection
  6. Photo Publishing to Social Websites (Facebook, MySpace, Twitter, Plurk, and Blogger)
  7. Photo Sharing by Email
Print Server
  1. Max No. of Printers: 3
  2. Supports Internet Printing Protocol
    • Print Job Display and Management
    • IP- and Domain Name-based Privilege Control
  3. Supports Apple Bonjour Printing
Music Station
  1. Plays or Shares Music Collections with Web Browser
  2. Automatic Classification via Media Library
  3. Supported audio format: MP3, FLAC, OGG, WAV, AIF, AIFF, and more.
    * DRM encryption format is not supported.
  4. Internet Radio (MP3)
  5. Up to 8 Music Alarms
Syslog Server
  1. Centralized Log Monitoring and Archiving
  2. Immediate E-mail Alerts
  3. Supports Log Filtering
Download Station
  1. PC-less BT, FTP, HTTP Download (up to 500 Tasks)
  2. BT Download
    • Supports Magnet Links
    • Supports TCP/UDP Tracker Protocol
    • Scheduled Download
    • Configurable Port Range
    • Bandwidth Control
    • RSS Subscription and Download (Broadcatching)
    • Selectable Download Files
  3. HTTP/ FTP Download
    • Configurable Saving Directory
    • Bulk Download with Wildcard Settings
    • RapidShare Download Support
  4. QNAP Download Management Software: QGet
    • For Both Windows & Mac OS
    • Manage the Download Tasks of Multiple QNAP NAS Remotely over LAN or WAN
  1. Centralized Account Management and Authentication for Network Access
  2. Supports PAP, EAP-TLS/PAP, and EAPTTLS/PAP Authentication
QPKG Center
  1. Expands Application Services by Easy Online Installation
  2. A Wide Variety of Official and Community QPKG Add-ons
TFTP Server with PXE Booting
VPN Server
  1. Secure Remote Access: PPTP & OpenVPN VPN services
  2. Remote Access to Other Resources on Local Network
  3. Max No. of Clients: 30
Surveillance Station
  1. Max. IP Cameras: 16, optional purchase (2 free license included, supported network cameras)
  2. Mobile app: Vmobile (iOS & Android)
*The data encryption functions may not available in accordance to the legislative restrictions of some countries.
Design and specifications are subject to change without notice

Informations complémentaires

Poids8 kg
Dimensions40 × 40 × 40 cm


Emplacements disques

1 -> 4


4To – 8To

Raid supporté

0, 1, 10, 5, 6, JBOD

Attachement direct


Ports réseau


Alimentation redondante





1 an J+1 pièces


4x 2To SATA, 4x 4To SATA, 1x 8To SATA, 2x 8To SATA, 3x 8To SATA, 4x 8To SATA, 1x 16To SATA, 2x 16To SATA, 3x 16To SATA, 4x 16To SATA
